DAE/DTDM should be greyed out and is not applicable here. In that same window, click on the Audio tab and make sure that Audio Sync Mode is set to External/Free next to Core Audio. If they are different, you may not get the expected sync results - for instance, if Pro Tools is set to 1 hour and Logic to 0 (zero) hours, you would press play in Pro Tools and have to wait 1 hour until Logic would start to sync. This assures that Bar 1 in Pro Tools, which is at 1 hour, is the same in Logic. Bar position (1 1 1 1) plays as SMPTE 01:00:00:00 is what you should see there. In the Frame Rate drop down, choose the same frame rate that you have set in Pro Tools. No need to check 'Auto Enable External Sync'. In Logic, go to Settings>Sychronization, then click on the General tab. Under MTC Reader and Generator select IAC Driver Bus 1 next to MTC Generator Port, then click OK. In Pro Tools go to Setup>Peripherals and click on the Synchronization tab. Open the tab for 'Time Code Settings' and in the lower left, check the box for 'Using MTC'. Verify the Time Code Rate you want to use (30 for audio only, 29.97 for NTSC video, etc.).
In Pro Tools go to Setup>Session and change the Session Start to 1 hour (01:00:00:00) in the upper right. Close the IAC Driver window - it should now show up as 'active' (not greyed out) in the Audio MIDI Setup window. The 'apply' button won't ever light up - this is normal. Double click on the IAC Driver and check the box for 'Device is online' and make sure at least 1 bus is showing in the Ports list. Applications>Utilities or through Pro Tools through the Setup>MIDI>MIDI Studio menu).
